Alignment: Specifications
Toe-In

Front

GENERAL SPECIFICATIONS

Angle (Left + Right):

Minimum .......................................................................................................................................................................................................  8' (0.13°)
Nominal .......................................................................................................................................................................................................  14' (0.23°)
Maximum ....................................................................................................................................................................................................  20' (0.33°)

Distance (A - B):

Minimum .....................................................................................................................................................................................  1.5 mm (0.059 inch)
Nominal .......................................................................................................................................................................................  2.5 mm (0.098 inch)
Maximum .....................................................................................................................................................................................  3.5 mm (0.138 inch)

Rear

GENERAL SPECIFICATIONS

Angle (Left + Right):

Minimum .........................................................................................................................................................................................................  0' (0.0°)
Nominal .......................................................................................................................................................................................................  14' (0.23°)
Maximum ....................................................................................................................................................................................................  28' (0.47°)

Distance (A - B):

Minimum ............................................................................................................................................................................................  0 mm (0.0 inch)
Nominal .......................................................................................................................................................................................  2.5 mm (0.098 inch)
Maximum ........................................................................................................................................................................................  5 mm (0.197 inch)
