Alignment: Specifications

Front

GENERAL SPECIFICATIONS

Minimum .....................................................................................................................................................................................................  -1°30' (-1.50°)
Nominal .......................................................................................................................................................................................................  -0°45' (-0.75°)
Maximum .......................................................................................................................................................................................................  0°00' (0.00°)
Left And Right Difference .....................................................................................................................................................................  45' (0.75°) or less

Rear

GENERAL SPECIFICATIONS

Minimum .....................................................................................................................................................................................................  -1°40' (-1.67°)
Nominal .......................................................................................................................................................................................................  -1°10' (-1.17°)
Maximum ....................................................................................................................................................................................................  -0°40' (-0.67°)

Caster

GENERAL SPECIFICATIONS

Minimum .......................................................................................................................................................................................................  6°00' (6.00°)
Nominal .........................................................................................................................................................................................................  6°45' (6.75°)
Maximum .......................................................................................................................................................................................................  7°30' (7.50°)
Left And Right Difference .....................................................................................................................................................................  45' (0.75°) or less

King Pin Inclination

GENERAL SPECIFICATIONS

Minimum ...................................................................................................................................................................................................  12°55' (12.92°)
Nominal .....................................................................................................................................................................................................  13°40' (13.67°)
Maximum ...................................................................................................................................................................................................  14°25' (14.42°)

Front

GENERAL SPECIFICATIONS

Angle (Left + Right):

Minimum .......................................................................................................................................................................................................  8' (0.13°)
Nominal .......................................................................................................................................................................................................  14' (0.23°)
Maximum ....................................................................................................................................................................................................  20' (0.33°)

Distance (A - B):

Minimum .....................................................................................................................................................................................  1.5 mm (0.059 inch)
Nominal .......................................................................................................................................................................................  2.5 mm (0.098 inch)
Maximum .....................................................................................................................................................................................  3.5 mm (0.138 inch)

Rear

GENERAL SPECIFICATIONS

Angle (Left + Right):

Minimum .........................................................................................................................................................................................................  0' (0.0°)
Nominal .......................................................................................................................................................................................................  14' (0.23°)
Maximum ....................................................................................................................................................................................................  28' (0.47°)
