Vibe FWD L4-2.4L (2009)
Vehicle Lifting: Service and Repair
Lifting and Jacking the Vehicle
Danger: To avoid any vehicle damage, serious personal injury or death when major components are removed from the vehicle and the vehicle
is supported by a hoist, support the vehicle with jack stands at the opposite end from which the components are being removed and strap the
vehicle to the hoist.
Caution: Perform the following steps before beginning any vehicle lifting or jacking procedure:
*
Remove or secure all of the vehicle contents in order to avoid any shifting or any movement that may occur during the vehicle lifting or jacking
procedure.
*
The lifting equipment or the jacking equipment weight rating must meet or exceed the weight of the vehicle and any vehicle contents.
*
The lifting equipment or the jacking equipment must meet the operational standards of the lifting equipment or jacking equipment manufacturer.
*
Perform the vehicle lifting or jacking procedure on a clean, hard, dry, level surface.
*
Perform the vehicle lifting or jacking procedure only at the identified lift points. DO NOT allow the lifting equipment or jacking equipment to
contact any other vehicle components.
Failure to perform the previous steps could result in damage to the lifting equipment or the jacking equipment, the vehicle, and/or the vehicle contents.
Caution: When you are jacking or lifting a vehicle at the frame side rails or other prescribed lift points, be certain that the lift pads do not contact the
catalytic converter, the brake pipes or the fuel lines. If such contact occurs, vehicle damage or unsatisfactory vehicle performance may result.
Note: The use of a LOW PROFILE LIFT ARMS SYSTEM may be necessary in order to avoid unwanted contact with the vehicle body. Refer to the
lifting equipment manufacturer's recommendations.
Swing Arm Type Lift
1 - Center of Gravity
2 - Front Hoist Pads
3 - Rear Hoist Pads
Vehicle Lifting and Jacking Locations - All Wheel Drive Model
