Timing Belt: Diagrams
Key to Image
1- Hexagon head bolt M 16 x 1.5 x 60 - Tightening torque 210 Nm (155 ft lb)
2- Washer
3- Pulley
4- Pan head screw M 6 x 25 - Tightening torque 15 Nm (11 ft lb)
5- Tab washer
6- Pulley
7- Gear drive for balance shafts
8- Flange washer
9- Hexagon head bolt M 10 x 30
10- Washer A 10.5
11- Pulley
12- Locknut M 10
13- Washer A 10.5
15- Hexagon head nut
16- Washer A 8.4
17- Hydraulic toothed belt tensioner
