Female

Make

Rover

Model

400 Electrical Library

Year

1998 model year on

Section

C0033 › Female

ConnectorsFemale · page 1 of 2

Main harness to body harness - LHD

Female

BLUE

Behind LH side of fascia

Cav	Col	CCT
1	LGB	7
1	LGB	79
2	G	7
2	G	79
3	GW	69
3	GW	79
4	WY	69
4	WY	79
5	GB	69
5	GB	79
6	WR	69
6	WR	79

Cav	Col	CCT
7	YR	69
7	YR	79
8	RW	69
8	UW	79
9	RU	69
9	UR	79
10	UG	26
10	UG	69
11	GO	19
11	YG	69
12	GU	69
12	GU	79
