Male

Make

Rover

Model

400 Electrical Library

Year

1998 model year on

Section

C0067 › Male

ConnectorsMale · page 1 of 2

Main harness to fascia harness - D Series

Male

LIGHT GREY

Behind passenger compartment fusebox cover

Cav	Col	CCT
1	UR	9
1	YU	69
2	UR	9
2	RY	70
3	RY	69
3	U	70
4	U	69
4	YG	70
5	YG	69
5	WB	70
6	WB	69
6	UY	70

Cav	Col	CCT
7	UY	69
7	RW	70
8	RW	69
8	UB	70
9	BY	69
9	UW	70
10	YB	69
10	GO	70
11	YR	69
11	O	70
12	UB	41
12	P	42
12	GO	69
