Male

Make

Rover

Model

400 Electrical Library

Year

1998 model year on

Section

C0105 › Male

ConnectorsMale · page 1 of 2

Main harness to body harness - LHD

Male

BLUE

Behind footwell trim panel - LH side

Cav	Col	CCT
1	LGB	7
1	LGB	74
2	G	7
2	G	74
3	GW	74
3	GW	77
4	WY	74
4	WY	77
5	GB	74
5	GB	77
6	WR	74
6	WR	77

Cav	Col	CCT
7	YR	74
7	YR	77
8	UW	74
8	UW	77
9	UR	74
9	UR	77
10	UG	28
10	UG	28
10	UG	29
10	UG	29
11	YG	74
11	YG	77

05 General
