Female
- Make
- Rover
- Model
- 400 Electrical Library
- Year
- 1998 model year on
- Section
- C0550 › Female
ConnectorsFemale
Joint connector
Female
ORANGE
Base of ’C’ post - LH side
| Cav | Col | CCT |
|---|---|---|
| 1 | GW | 77 |
| 2 | GW | 77 |
| 3 | GW | 77 |
| 5 | RY | 77 |
| 6 | RY | 77 |
| 7 | RY | 77 |
| 8 | GB | 77 |
| 9 | GB | 77 |
| 10 | GB | 77 |
