Female
- Make
- Rover
- Model
- 400 Electrical Library
- Year
- 1998 model year on
- Section
- C0623 › Female
ConnectorsFemale
Main harness to heater A/C harness
Female
GREY
Behind RH headlamp
| Cav | Col | CCT |
|---|---|---|
| 3 | W | 69 |
| 4 | BU | 69 |
| 6 | R | 69 |
| 7 | UR | 69 |
| 8 | YW | 69 |
