Drive Belt: Specifications (page 6 of 8)

Make

Saab

Model

9000

Engine

L4-2290cc 2.3L DOHC

Year

1991

Section

Drive Belt

MaintenanceSpecifications · page 6 of 8

3. Slacken the belt by applying a hard pull upwards. Fix the belt tensioner in the compressed position by means of locking pin 83 94 488, or

equivalent.

4. Raise the car. Remove the tensioner idler-wheel pulley and the belt.

5. Remove the locking pin (e.g. use a pair of water-pump pliers or a large screwdriver). Watch your fingers!
