Timing Belt: Service and Repair (page 4 of 14)

Make

Saturn

Model

Astra

Engine

L4-1.8L

Year

2009

Section

Timing Belt

MaintenanceService and Repair · page 4 of 14

14. Block the crankshaft.

Attach KM-6625  .

1. Detach the screwed connection (1).
2. Insert KM-6625   (2).
3. Tighten the screwed connection (3).

15. Remove the torsional vibration damper.

Remove the bolt.

16. Remove the front toothed belt cover (bottom).

Remove the 4 bolts.

17. Remove KM-6625  .

Detach the screwed connection.
