Ignition Coil: Locations
- Make
- Saturn
- Model
- Aura
- Engine
- L4-2.4L Hybrid
- Year
- 2009
- Section
- Ignition System › Ignition Coil › Locations
Powertrain ManagementLocations · page 1 of 7
Ignition Coil: Locations
Powertrain Component Views
Top of Engine Components (LAT)
1 - Mass Air Flow (MAF) Sensor
2 - Camshaft Position (CMP) Actuator Solenoid - Intake
3 - Camshaft Position (CMP) Actuator Solenoid - Exhaust
4 - Ignition Coil Module 1
5 - Ignition Coil Module 2
6 - Ignition Coil Module 3
7 - Ignition Coil Module 4
8 - Throttle Actuator Control (TAC) Module
9 - Fuel Injector 4
10 - Fuel Injector 3
11 - Fuel Injector 2
12 - Fuel Injector 1
13 - Manifold Absolute Pressure (MAP) Sensor
14 - X130
