Wheel Alignment Specifications
- Make
- Saturn
- Model
- L Series L100
- Engine
- L4-2.2L VIN F
- Year
- 2001
- Section
- Alignment › Specifications › Wheel Alignment Specifications
Alignment: Specifications
Camber
Front Preferred Setting (Degrees)
-1.00 deg
Minimum (Degrees)
-1.50 deg
Maximum (Degrees)
-0.50 deg
Cross Camber
Preferred Setting (Degrees)
0.00 deg
Minimum (Degrees)
-1.00 deg
Maximum (Degrees)
+1.00 deg
Toe (Per Wheel)
Preferred Setting (Degrees)
+0.10 deg
Minimum (Degrees)
0.02 deg
Maximum (Degrees)
+0.18 deg
Total Toe
Preferred Setting (Degrees)
+0.20 deg
Minimum (Degrees)
0.04 deg
Maximum (Degrees)
+0.36 deg
Caster is Not Adjustable
Caster
Preferred Setting (Degrees)
+3.70 deg
Minimum (Degrees)
+3.20 deg
Maximum (Degrees)
+4.20 deg
Cross Caster
Preferred Setting (Degrees)
0.00 deg
Minimum (Degrees)
-1.00 deg
Maximum (Degrees)
+1.00 deg
Total Toe
Rear
Preferred Setting (Degrees)
+0.3 deg
Minimum (Degrees)
+0.13 deg
Maximum (Degrees)
+0.47 deg
Camber is Not adjustable
Caster is Not Adjustable
Camber
Preferred Setting (Degrees)
-1.00 deg
Minimum (Degrees)
-1.50 deg
Maximum (Degrees)
-0.50 deg
Cross Camber
Preferred Setting (Degrees)
0.00 deg
Minimum (Degrees)
-0.50 deg
