Gear oil level|replace > < Gear oil level

Leon Mk1

checking and completing
checking and completing
–  Raise the vehicle.

–  Remove bolts -1- and - 2- and remove central soundproofing panel.
  A10-10761
–  Loosen oil level test and filler plug.
l  Specification: oil level up to lower edge of filler hole.
Oil specification for gears → Chapter.
–  If the oil level is not correct, complete oil level.
–  Unscrew control lid, start engine and let the gears work with engaged gear for about 2 minutes.
–  Stop the engine, remove oil cap and check level again, top up if necessary.
–  Screw the oil level control lid and tighten with the appropriate torque → Chapter.
–  Install the middle soundproofing.
  N34-10577
