Leon Mk1

Remove the front door trim
Remove the front door trim
  Note
t  The trim of the front doors is always destroyed during the removal.
t  Gloves and safety glasses must always be worn when removing the front door trim.

–  Heat the adhesive tape -2- by using the hot air gun -SAT 1416-.
–  Lift the bottom of the front door trim -1- by using the lever -U 30800-.
  Note
When heating the adhesive tape -1- by using the hot air gun -SAT 1416-, simultaneously remove the front door trim -2- by using the lever -U 30800-.
  E66-10090
