Installation

Installation is carried out in the reverse sequence; note the following:

–	Install the rear section of the cardan shaft → Final group 0AV; Rep. gr.39.

–	Install the vehicle level sender → Chapter.

–	Bleed brake system → Rep. gr.47 .

Specified torques

Component

Tightening torque

Subframe to body

t	Use new bolts.

90 Nm + 90°

Shock absorber to wheel bearing housing

180 Nm

Mounting bracket to body

t	Use new bolts.

50 Nm +45°

Handbrake cable to trailing arm
→ Brake systems; Rep. gr.46

–	Check and adjust wheel alignment → Chapter.
