Octavia Mk1
1 - | Torx screws, 8 Nm |
2 - | Hydraulic unit |
The hydraulic unit consists of: -a- Hydraulic pump for ABS or ABS/TCS/EDL -V64--b- Hydraulic unit for ABS or ABS/TCS/EDL -N55- |
t | the valve block includes the control valves |
t | after separating them from the control unit, fit on the transport protection for valve domes |
3 - | Control unit for ABS or ABS/TCS/EDL -J104- |
t | when removing them from the hydraulic unit, the valve domes of the hydraulic unit must not tilt along with the solenoid coils of the control unit |
t | Cover the solenoid coils with a non-fluffing cloth |
t | Contact assignment → Chapter |
t | Test requirements → Chapter |
Note
|
