Forester F4-2.5L SOHC (2004)
4. Apply an even coat of specified grease [20 to 30 g (0.71 to 1.06 oz)] to the entire inner surface of boot. Also apply grease to the shaft.
NOTE: The inside of the larger end of AC boot and boot groove shall be cleaned so as to be free from grease and other substances.
5. Install the boot projecting portion to AC groove.
6. Set the large boot band in place.
NOTE: Make sure to recognize the position of retainer.
7. Install the boot projecting portion to shaft groove.
8. Tighten the boot bands using ST, torque wrench and socket flex handle.
ST 28099AC000 BOOT BAND PLIER
Caulked portion clearance of boot band:
Large boot band 1.3 mm (0.051 inch) or more
Small boot band 1.3 mm (0.051 inch) or more
9. Fit the AAR boot and retainer to shaft, and then position to center of shaft.
