5. Repeat this operation until there are no more air bubbles in hydraulic line.

6. When bubbles stop, depress and hold brake pedal and tighten bleeder plug.

Tightening torque

Front bleeder plug: 10.0 Nm (1.0 kgf-m, 7.5 ft. lbs.)
Rear bleeder plug: 8.0 Nm (0.8 kgf-m, 6.0 ft. lbs.)

7. Then attach bleeder plug cap.
8. After completing bleeding operation, apply fluid pressure to pipe line and check for leakage.

9. Replenish fluid into reservoir up to specified level.

10. Check brake pedal for sponginess. If found spongy, repeat entire procedure of bleeding.
