Body and FrameSpecifications · page 3 of 5
8. Open the front door and remove the bolt at the base of the A-pillar.
9. Reposition the cowl vent grille weatherstrip.
10. Remove the upper fender bolts and the fender.
Fender Installation
CAUTION: Dissimilar metals in direct contact with each other may corrode rapidly. Make sure to use the correct fasteners to prevent premature
corrosion.
1. Install the fender with the upper fender bolts.
Tighten:
Tighten the upper fender bolts to 10 N.m (89 lb.in).
