Wheel Bearing: Specifications



Wheel bearing lock nut (a)

216 Nm









Lock bearing lock screw (a)

1.5 Nm









Wheel bearing thrust play limit

0.05 mm









Rear wheel bearing thrust play

Limit 0.8 mm
