Drive Belt: Specifications
Drive Belt Tension

Drive Belt Tension

New Belt

Used Belt









Generator Drive Belt

175 +/- 5 lbf

115 +/- 20 lbf









A/C Drive Belt

165 +/- 26 lbf

88 +/- 22 lbf









Power Steering Drive Belt

150 - 185 lbf

115 +/- 20 lbf
