Ball Joint: Specifications
INSPECT LOWER BALL JOINT ASSEMBLY FRONT LH
a. As shown in the illustration, flip the ball joint stud back and forth 5 times, before installing the nut.
b. Using a torque wrench, turn the nut continuously at a rate of 3 - 5 seconds per 1 turn and take the torque reading on the 5th turn.
Turning torque: 0.98 - 3.43 Nm (10 - 35 kgf-cm, 8.7 - 30 inch lbs.)
