Matrix 4WD L4-1.8L (1ZZ-FE) (2004)

Page 1
background image

Flywheel: Specifications

FLYWHEEL SUB-ASSY (M/T TRANSAXLE)

Torque: 49 Nm (500 kgf-cm, 36 ft. lbs.)
Retighten the bolts by an additional 90°.

Maximum runout: 0.1 mm (0.004 inch)
