RAV4 2WD L4-2.4L (2AZ-FE) (2004)
/Page-870001.png)
Flywheel: Specifications
Flywheel Runout.
Maximum runout: ............................................................................................................................................................................... 0.1 mm (0.004 inch)
Install the 8 mounting bolts in several passes, in the sequence shown.
Torque: .......................................................................................................................................................................... 130 Nm (1,325 kgf-cm, 96 ft. lbs.)
