Solara Coupe L4-2.4L (2AZ-FE) (2007)

Page 1
background image

Flywheel: Specifications

Flywheel

Install the flywheel with the 8 bolts. Uniformly tighten the 8 bolts in the sequence shown in the illustration.
Torque ........................................................................................................................................................................  130 Nm (1,330 kgf-cm, 96 ft. lbs.)
