Pick-Up Coil, Ignition > < Igniter <--> [Ignition Control Module]|Locations|Page 1010

Starlet L4-1290cc 4KE (1983)

Page 1
background image

Ignition Relay: Locations

Fuse & Relay Locations.

 Relay Block, Behind LH Side Kick Panel

Applicable to:  1983-84 Models
