Drive Belt: Specifications

Make

Toyota

Model

Supra

Engine

L6-183 2997cc 3.0L DOHC (2JZ-GE)

Year

1993

Section

Drive Belt › Specifications

MaintenanceSpecifications

Drive Belt: Specifications

Fig. 15 Drive Belt Tension Inspection

Check that the belt tensioner moves downward when drive belt is pressed down at points in Fig. 15 with approximately 22 ft. lbs.

Check that arrow mark on belt tensioner falls within area A in Fig. 16. If new belt is installed, it should be within area B.
