CAMBER, CASTER AND STEERING AXIS INCLINATION

Camber .....................................................................................................................................................................................................  0° 00' ± 45'
Left-Right Error ..........................................................................................................................................................................................  45'  or less
Caster .......................................................................................................................................................................................................  1° 20' ± 45'
Left-Right Error ...........................................................................................................................................................................................  45' or less
Steering Axis Inclination ......................................................................................................................................................................  11° 50' ± 45'
Left-Right Error ...........................................................................................................................................................................................  45' or less

TOE-IN

Measuring Point Reference

P215/75 R15
INSPECT
A+B .........................................................................................................................................................................................................  -0.36° ± 0.2°
C-D ..............................................................................................................................................................................  -4.7 ± 2 mm (-0.18 ± 0.08 in.)
ADJUST
A+B .........................................................................................................................................................................................................  -0.36° ± 0.1°
C-D ..............................................................................................................................................................................  -4.7 ± 1 mm (-0.18 ± 0.04 in.)

P235/75 R15
INSPECT
A+B ..........................................................................................................................................................................................................  0.36° ± 0.2°
C-D ................................................................................................................................................................................  4.9 ± 2 mm (-0.19 ± 0.08 in.)
ADJUST
A+B ..........................................................................................................................................................................................................  0.36° ± 0.1°
C-D ................................................................................................................................................................................  4.9 ± 1 mm (-0.19 ± 0.14 in.)

WHEEL ANGLE

Inside Wheel ......................................................................................................................................................................................................  40°10'
Outside Wheel (Reference) ...............................................................................................................................................................................  34°25'
Left-Right Error ......................................................................................................................................................................................................  30'

RACK END DIFFERENCE

Rack end difference ............................................................................................................................................................  3.0 mm (0.118 in.) or less
Tie rod end lock nut ..........................................................................................................................................................................  56 N.m (41 ft lb)

Standard Cab

STANDARD CAB

CAMBER, CASTER AND STEERING AXIS INCLINATION

Camber .......................................................................................................................................................................................................  0° 0' ± 45'
