T100 Pickup 4WD V6-180.5 2959cc 3.0L SOHC (3VZ-E) (1993)

Page 1
background image

Valve Spring Shim: Application and ID

Shims are available in 25 sizes in increments of 0.05 mm (0.0020 in.), from 2.20 mm (0.0984 in.) to 3.40 mm (0.1299 in.).

INTAKE SHIMS
