Timing Belt Removal for T100 Pickup 4WD V6-1805 2959cc 30L SOHC (3VZ-E) (1993) Engine
![background image](/toyota/t100_pickup_4wd/v6-180.5_2959cc_3.0l_sohc_(3vz-e)/Page-313003.png)
14. Remove the two mount nuts and the water outlet.
15. Using a screwdriver, disconnect the four spark plug cable clamps from the mounting bolts of the No.2 timing belt cover.
16. Using appropriate sized nuts, remove the two stud bolts.
17. Remove the eleven mount bolts, timing belt cover and three gaskets.
18. If re-using the timing belt, make sure the installation marks line up as shown. If they have worn off, place new ones on there as shown.
