Tacoma PreRunner L4-2.7L (3RZ-FE) (2004)
Brake Bleeding: Service and Repair
BRAKE FLUID
BLEEDING
HINT: If any work is done on the brake system or if air is suspected in the brake lines, bleed the air from the system.
NOTICE: Do not let brake fluid remain on a painted surface. Wash it off immediately.
1. FILL BRAKE RESERVOIR WITH BRAKE FLUID
Check the fluid level in the reservoir after bleeding each wheel. Add fluid, if necessary.
Fluid: SAE J1703 or FMVSS No. 116 DOT3
2. BLEED MASTER CYLINDER
HINT: If the master cylinder was disassembled or if the reservoir becomes empty, bleed the air from the master cylinder.
a. Disconnect the brake lines from the master cylinder.
SST 09023-00100
b. Slowly depress the brake pedal and hold it.
c. Block off the outlet plug with your finger, and release the brake pedal.
d. Repeat (b) and (c) 3 or 4 times.
