Flywheel: Specifications



Flywheel Bolts

2.4L (2RZ-FE) Engine

88 Nm











2.7L (3RZ-FE) Engine

Step 1

26.5 Nm













Step 2

Additional 90 degrees













3.4L (5VZ-FE) Engine

85 Nm













Flywheel Runout

Maximum Runout

0.1 mm











Sequence

Sequence
