Alignment (Service Data): Specifications

Make

Toyota

Model

Venza FWD

Engine

V6-3.5L (2GR-FE)

Year

2010

Section

Alignment › Specifications › Service Data

MaintenanceService Data · page 1 of 3

Alignment: Specifications
Service Data

SPECIFICATIONS: ALIGNMENT / HANDLING DIAGNOSIS: SERVICE DATA

Vehicle Height (Unloaded Vehicle)

Measurement points:

*

A: Ground clearance of front wheel center

*

B: Ground clearance of No. 2 lower suspension arm bushing set bolt center

*

C: Ground clearance of rear wheel center

*

D: Ground clearance of strut rod set bolt center

Camber (Unloaded Vehicle)

Caster (Unloaded Vehicle)

Steering Axis Inclination (Unloaded Vehicle)
