Field Remedy: 2483

Remedy:

Most turbocharger failures are caused by one of the three basic
reasons:

     • Lack of Lubrication
     • Oil Contamination
     • Foreign Object Damage

Turbocharger parts overview:

1. Turbin housing
2. Thrust bearing
3. Compressor wheel
4. REA (Elektronic Actuator)
5. Compressor housing
6. Journal bearing
7. Nozzle ring assembly (turbine wheel)

Many turbochargers are replaced needlessly because a trouble-shooting
procedure is not being followed.

Please use the following Turbocharger Diagnosis Table before replacing
parts:

Defect Mode        Description                  Action
______________________________________________________________________

Noise:

            |  Compressor & Turbine      |  Check for foreign object
            |  Wheel damaged and bent    |  ingestion

            |  Incorrect wheel rotation  |  Check for oil
            |  or interference with      |  contamination
            |  housing                   |  Check oil replacement
                                         |  (service records)

            |  Leak between exhaust      |  Check fitting of component
            |  manifold & cylinder head
            |  or turbine housing inlet

            |  Air hose damage or clamp  |  Replace air hose or
            |  tightening torque         |  re-tighten clamp
            |  insufficient
______________________________________________________________________

Leak:

            |  Engine oil Leak           |  Check turbo oil feed pipe
                                         |  and washer for damage

            |  Blow-by gas leak          |  Check intercooler hose
                                         |  connections and securing
                                         |  clamp
______________________________________________________________________

Lack of power or poor acceleration:

            |  No intercooler hose       |  Check compressor wheel for
            |  expansion during          |  damage and REA performance
            |  acceleration

            |  Incorrect compressor and  |  Check for oil
            |  turbine wheel rotation    |  contamination
                                         |  Check oil replacement
                                         |  (service records)
__________________________________________________________________________
