Instruments, Telltales (Exploded View): Description and Operation

Exploded View

1     Gauge mechanism

2     Electronic printed circuit board

3     Housing

4     Flexible printed circuit board

5     Coloured disc fastened in (3)

6     Gauge mechanism

7     Electronic speedometer

8     Fibre - optical light guide

9     Light channel

10   Dial, cemented to (8) and (9)

11   Front frame

12   Adjustment buttons MID / TID

13   Cover glass with heated blocking foil

14   Beading welded to (13)

15   Rubber cap cemented to (1 1)

16   Luminous pointer
