Golf Mk6
| Overview of connectors on radio navigation system „RNS 510“ |
| 1 - | Connection for navigation, Japan |
| q | Not assigned |
| 2 - | Aerial connection |
| q | DAB aerial input connection, optional |
| 3 - | Multi-pin connector 1, 8-pin |
| q | Pin assignment → Chapter |
| 4 - | Multi-pin connector 2, 8-pin |
| q | Pin assignment → Chapter |
| 5 - | Multi-pin connector 3, 12-pin |
| q | Pin assignment → Chapter |
| 6 - | Multi-pin connector 4, 12-pin |
| q | Pin assignment → Chapter |
| 7 - | Multi-pin connector, 26-pin |
| q | Pin assignment → Chapter |
| 8 - | Aerial connection |
| q | For Navigation |
| q | For further information → Chapter |
| 9 - | Aerial connection |
| q | FM 2 aerial |
| q | For further information → Chapter |
| 10 - | Aerial connection |
| q | FM/AM aerial |
| q | For further information → Chapter |
