Relay Box: Locations

Make

Volkswagen

Model

Touareg

Engine

V8-4.2L (BHX)

Year

2004

Section

Relay Box › Locations

Power and Ground DistributionLocations · page 1 of 4

Relay Box: Locations

Fig. 1 Relay positions of relays in E-box (in plenum chamber, left)

Position

Relay

A3

Motronic Engine Control Module (ECM) Power Supply Relay -J271-

A4

Secondary Air Injection (AIR) Pump Relay -J299-

A5

Coolant Circulation Pump Relay -J151-

A6

Fuel Pump (FP) 2 Relay -J49-
-

Fuel Pump (FP), left

C19

Power Supply Relay (terminal 50) -J682-

C20

Fuel Pump (FP) Relay -J17-
-

Fuel Pump (FP), right
