C70 Convertible L5-2.4L Turbo VIN 56 B5244T (2000)
Convertible Top Frame: All Technical Service Bulletins
Campaign - Tension Bow Seal Deformed
Section
8
Group
84
No.
0022
Year
99
Month
06
C70
1998
Reference: TP 8307201, Section 8 (83), Convertible system, C70 Convertible 1998.
Vehicles Involved: Convertible
Campaign No. 91 G
Tension bow seal
Background:
The two end pieces of the sealing strip for the tension bow may deform and in some cases, cause wind noise or cause water to enter the convertible top
storage well. The new tension bow seal has an improved fit.
Materials:
Description
Quantity
Part no.
Sealing strip
1
8618998
Tension bow seal
1
Preparations
Raise the tension bow with button on the dash as per illustration.
2
Removing the tension bow seal
Note!
The screws must be removed by hand with torx bits and handle. This is to determine if any of the threads in the frame are stripped.
