C70 Convertible L5-2.4L Turbo VIN 56 B5244T (2000)
Convertible Top Latch: All Technical Service Bulletins
Campaign - Lock Brace, Inspection & Replacement
Section
8
Group
83
No.
0015
Year
99
Month
06
C70
1998
Reference: TP 8307201, Section 8(83), Convertible System, C70 Convertible 1998-
Vehicles involved: Convertible
Campaign No. 91H
Lock brace, inspection and replacement
Background:
If any of the lock braces securing the tension bow to the cover plate (with the convertible top in raised position) does not enter the lock catch and secure
the tension bow to the cover plate correctly, water leakage may occur in the convertible top storage well when it rains.
Materials:
Description
Quantity
Part no.
Lock brace L
1
8614945
Lock brace R
1
8614946
Lock brace, inspection and replacement
Inspecting and replacing the lock brace
1
Preparations
Raise the tension bow with button on dash as per illustration.
2
Inspecting the lock brace
