C70 Convertible L5-2.4L Turbo VIN 56 B5244T (2000)
Convertible Top Weatherstrip: Technical Service Bulletins
Campaign - Header Seal
Section
8
Group
84
No.
0015
Year
99
Month
06
C70
1998
Campaign No. 91A
Header seal
Background:
To prevent possible infiltration of rainwater to the interior of the vehicle, additional sealing steps are to be taken on both sides of the vehicle.
Materials:
Description
Quantity
Part no.
Butyl tape
1/3 (2x120 mm)
9152636
3M Auto bedding and glazing
1/2
Locally supplied
compound, P/N 051135-08509
Silicone Sealant
1/2
1161277
Seal insert
2
9474894
Header Seal
1
This picture is to show where the sill-molding clip is 10- located on the passenger's side of the vehicle.
Note!
These steps are to be performed on both sides of the vehicle.
