Page 7
background image

Install the wheel bearing unit with new screws.
Lubricate the outer threads a little and tighten crosswise to 65 Nm (47.9 ft. lbs.).
Angle-tighten the screws for the wheel bearing unit to 60°. Use protractor 951 2050.

Finishing

Check the drive shaft for damage to the mating surfaces with the wheel bearing.
Check the booms (splines).
Clean the pulse wheel and check the shape of its cogs.
Lubricate the booms (splines) and mating surfaces to the wheel bearing a little.

Detach the drive shaft from where it was placed earlier.
Turn the spring strut a half turn to detach it from the control arm.

Note!  Take care not to damage the brake hose.
