C70 Convertible L5-2.4L Turbo VIN 56 B5244T (2000)
Install the drive shaft in the hub by hand, but only to the extent that the drive shaft can easily move backward and forward in its position
Lubricate a new drive shaft screw and screen it in a few turns by hand.
Clean off any rust from the ball joint and stub axle.
Lubricate the ball joint pinion and the stub axle.
Install the ball joint in the stub axle
Note! Press the ball joint upwards so that the conical top is visible above the screwed joint on the stub axle.
Install the screw and a new nut.
Tighten to 50 Nm (36.9 ft. lbs.).
Check the dust boot on the anti-roll bar link for damage.
Check the link threads for damage.
Lubricate the threads.
Reinstall the upper link of the anti-roll bar on the spring strut. Use a new locknut. Tighten to 50 Nm (36.9 ft. lbs.).
Install the tie rod on the stub axle. Use a new locknut.
Tighten to 70 Nm.
