C70 Coupe L5-2.3L Turbo VIN 53 B5234T3 (2001)
Control Assembly: Service and Repair
Replacing Or Adjusting Control Cables/Mechanical Rear Section And Control Panel/Front Section (Manual Climate Control/STANDARD)
Preparations
Passenger side
-
Remove the glove compartment.
-
Remove the soundproofing panel.
-
Remove the floor air ducts.
-
Disconnect the control cable from the climate control.
Driver's Side
