A8L V8-4.2L (BFM) (2004)
-
Remove the bolt - 1 - from the track control arm.
-
Remove the bolt - 3 - from the trailing arm.
-
Remove the wheel bearing housing from the drive axle and from the suspension.
-
If the wheel hub and bearing will be removed, clamp the wheel bearing housing in a vise with protective covers.
-
To remove wheel hub and bearing, remove the bolts - arrows -.
CAUTION!
‹› Avoid contaminating with dirt and damaging the seal when setting down/storing.
The wheel hub and bearing slide washer - 1 - must always face up.
-
Always set the wheel bearing down on the wheel hub - 2 -.
Installing
