5 Series E39 M5 (S62) SAL
Attach VANOS adjustment unit.
Caution!
Ensure that both VANOS splined shafts remain in initial
position during assembly procedure.
Rotate splined shafts of inlet and exhaust sides until straight
splines are engaged.
Push VANOS adjustment unit with splined shaft into VANOS gear
until helical cut splines (2) are positioned shortly before meshing
with spline hub (1).
Exhaust side:
If the helical cut splines cannot be pushed into the spline hub (1):
Place special tool 11 7 150 on bore in spline hub (1). Rotate
spline hub (1) against direction of rotation until splined shaft (2)
is positioned with spline hub (1) exactly "tooth-to-tooth gap".
Caution!
The "first" fitting tooth must snap into place.
Intake side:
Place special tool 11 7 150 on bore in spline hub (1). Rotate
spline hub (1) against direction of rotation until splined shaft (2)
is positioned with spline hub (1) exactly "tooth-to-tooth gap".
Caution!
The "first" fitting tooth must snap into place.
RA Removing and installing/replacing toothed shafts of VANOS gear on right (S62)
