Freelander Service Procedures
INTERIOR TRIM COMPONENTS
REPAIRS 76-3-23
Drink tray assembly - fascia - up to 04MY
$% 76.46.41
Remove
1. Open cup holder and remove both rubber mats.
2. Remove 2 screws securing cup holder
assembly and remove assembly.
Refit
1. Position cup holder assembly and secure with
screws.
2. Fit rubber mates and close cup holder.
Stowage box - fascia
$% 76.46.45
Remove
1. Remove mat from stowage box to access
screws.
2. Remove 2 screws.
3. Remove stowage box from fascia.
Refit
1. Position stowage box and secure with screws.
2. Fit mat to stowage box.
M76 4400
