Catera V6-3.0L VIN R (1997)
18. Remove the stabilizer shaft link connection at the rear axle lower control arm.
19. Support the rear cradle at the rear differential.
20. Scribe a reference mark on the vehicle body around the perimeter of the rear axle cradle mount to ensure proper reinstallation.
21. Remove the rear axle cradle mount bolts to the vehicle body.
Important: Support the lower control arm when removing the shock absorber lower mount bolt.
22. Remove the lower shock absorber mount bolt.
23. Remove the lower rear cradle to allow for rear spring removal.
24. Remove the rear spring.
