SRX AWD V6-3.6L (2008)
3. Disconnect the Bank 1, Sensor 1 heated oxygen sensor pigtail from the wiring harness connector (1).
4. If the vehicle is equipped with all wheel drive (AWD), remove the right outer tie rod end from the steering knuckle to gain access to the upper rear
exhaust manifold shield bolt. Refer to Rack and Pinion Outer Tie Rod End Replacement (See: Steering and Suspension/Steering/Tie Rod/Tie Rod
End/Service and Repair) .
5. Remove the bolts securing the engine wiring harness bracket to the right cylinder head.
Position the wire harness bracket aside.
6. Remove the right exhaust manifold heat shield bolts.
7. Reposition the shield forward in vehicle in the area where the generator mounts, to gain access to the exhaust manifold bolts.
