Coolant Line/Hose: Locations

Make

Cadillac

Model

STS RWD

Engine

V8-4.6L

Year

2007

Section

Hoses › Coolant Line/Hose › Locations

MaintenanceLocations

Coolant Line/Hose: Locations

After Boil Heater Pump

After Boil Heater Pump

1 - Heater Hose
2 - Radiator
3 - Cooling Fan - Right
4 - After Boil Heater Pump (LH2/V92 Only)
5 - Cooling Fan - Left
